DIN 1.2714
DIN 1.2714 is a hardened and air quenched die steel with good full hardened properties and toughness.
The high Nickel content imparts the toughness as well as good through-hardening (hardenability) in large section thicknesses.The steel also exhibits good resistance to thermal shock and thermal fatigue cracking, and relatively small dimensional changes during hardening.
Applications
- - Die Blocks
- - Die Inserts
- - Die Holders
- - Saw Blocks
- - Hot Shears
- - Hot Punching tools
Specifications
| Grade | % | C | Mn | Si | Ni | Cr | Mo | V | S | P |
|---|---|---|---|---|---|---|---|---|---|---|
| DIN 1.2714 | MIN. | 0.50 | 0.65 | 0.10 | 1.50 | 1.00 | 0.45 | 0.07 | MAX. | MAX. |
| MAX. | 0.60 | 0.95 | 0.40 | 1.80 | 1.20 | 0.55 | 0.12 | 0.015 | 0.020 |
